The PWS-4600 sets the standard for quality.

Features

• Powder coated paint resists flaking and peeling
• 80,000psi ductile iron body with increased nickel content for improved corrosion resistance
• Hardened vise bed and jaw plates
• Sealed and lubricated needle roller thrust bearing for maximum life and minimum torque
• Up to 7,000lbs. of clamping force
• Repeatability within .001" (0.025mm)
• Outside rails of body are machined within 0.0005" (.013mm) square to jaw
• Bed height matched to size 2.250" +/- 0.0005"
• Footprint and distance from the keyway to stationary jaw meets industry standard

Specifications

Type	Single Station
Style	Machinable Jaws
Clamping Pressure	7,000 lb
Jaw Opening	6.000 in
Jaw Width	4.000 in
Total Length	14.22 in
Total Width	6.30 in
Total Height	3.63 in
Material	Ductile Iron
Weight	33 lb

Country of Origin: Taiwan (Subject to Change)
