Dodeka Mini 15° High-Feed Shell Mill 63mm Dia with 6 Flutes 4153708
TITAN's Go-To Shell Mill!
- Twelve cutting edges per insert.
- Maximum number of teeth per diameter.
- Productivity booster in all materials.
- Face Milling
- Adapter Style: A-Socket Head Cap Screw
- Through Coolant: Yes
- Number of Flutes: 6
- Arbor Diameter (Inch): 0.8661"
- Arbor Diameter (Metric): 22.000mm
- Effective Cutting Diameter (Inch): 2.480"
- Effective Cutting Diameter (Metric): 63.000mm
- Maximum Cutting Diameter (Inch): 2.997"
- Maximum Cutting Diameter (Metric): 76.140mm"
- Maximum Cutting Depth (Inch): 0.064"
- Maximum Cutting Depth (Metric): 1.630mm
- Overall Length (Inch): 1.575"
- Overall Length: 40.000mm
- Max RPM: 10,100
Country of Origin is subject to change.
Safety data sheets upon request.
$332.92
Original: $951.20
-65%Dodeka Mini 15° High-Feed Shell Mill 63mm Dia with 6 Flutes 4153708—
$951.20
$332.92Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
TITAN's Go-To Shell Mill!
- Twelve cutting edges per insert.
- Maximum number of teeth per diameter.
- Productivity booster in all materials.
- Face Milling
- Adapter Style: A-Socket Head Cap Screw
- Through Coolant: Yes
- Number of Flutes: 6
- Arbor Diameter (Inch): 0.8661"
- Arbor Diameter (Metric): 22.000mm
- Effective Cutting Diameter (Inch): 2.480"
- Effective Cutting Diameter (Metric): 63.000mm
- Maximum Cutting Diameter (Inch): 2.997"
- Maximum Cutting Diameter (Metric): 76.140mm"
- Maximum Cutting Depth (Inch): 0.064"
- Maximum Cutting Depth (Metric): 1.630mm
- Overall Length (Inch): 1.575"
- Overall Length: 40.000mm
- Max RPM: 10,100
Country of Origin is subject to change.
Safety data sheets upon request.
