Dodeka Mini 45° Shell Mill 3" Dia with 8 Flutes 4130495

Product image 1

Dodeka Mini 45° Shell Mill 3" Dia with 8 Flutes 4130495

TITAN's Go-To Shell Mill!
  • Twelve cutting edges per insert.
  • Maximum number of teeth per diameter.
  • Productivity booster in all materials.
Applications
  • Chamfer Milling
  • Face Milling
Technical Data
  • Adapter Style: A-Socket Head Cap Screw
  • Through Coolant: Yes
  • Number of Flutes: 8
  • Arbor Diameter (Inch): 1.000"
  • Arbor Diameter (Metric): 25.400mm
  • Effective Cutting Diameter (Inch): 3.000"
  • Effective Cutting Diameter (Metric): 76.200mm
  • Maximum Cutting Diameter (Inch): 3.321"
  • Maximum Cutting Diameter (Metric): 84.348mm"
  • Maximum Cutting Depth (Inch): 0.127"
  • Maximum Cutting Depth (Metric): 3.230mm
  • Overall Length (Inch): 1.750"
  • Overall Length: 44.450mm
  • Max RPM: 8,300

Country of Origin is subject to change.

Safety data sheets upon request.

$396.57

Original: $1,133.06

-65%
Dodeka Mini 45° Shell Mill 3" Dia with 8 Flutes 4130495—

$1,133.06

$396.57
