Dodeka 45° End Mill 25mm Dia with 3 Flutes 4126352

Product image 1

Dodeka 45° End Mill 25mm Dia with 3 Flutes 4126352

TITAN's Go-To Indexable End Mill!
  • Twelve cutting edges per insert.
  • Maximum number of teeth per diameter.
  • Productivity booster in all materials.
Applications
  • Chamfer Milling
  • Face Milling
Technical Data
  • Adapter Style: Straight-Cylindrical
  • Through Coolant: Yes
  • Number of Flutes: 3
  • Arbor Diameter (Inch): 0.7874"
  • Arbor Diameter (Metric): 20.000mm
  • Effective Cutting Diameter (Inch): 0.984"
  • Effective Cutting Diameter (Metric): 25.000mm
  • Maximum Cutting Diameter (Inch): 1.306"
  • Maximum Cutting Diameter (Metric): 33.180mm"
  • Maximum Cutting Depth (Inch): 0.127"
  • Maximum Cutting Depth (Metric): 3.230mm
  • Overall Length (Inch): 4.724"
  • Overall Length: 120.000mm
  • Max RPM: 20,000

Country of Origin is subject to change.

Safety data sheets upon request.

$189.71

Original: $542.03

-65%
Dodeka 45° End Mill 25mm Dia with 3 Flutes 4126352—

$542.03

$189.71

Product Information

Shipping & Returns

Description

TITAN's Go-To Indexable End Mill!
  • Twelve cutting edges per insert.
  • Maximum number of teeth per diameter.
  • Productivity booster in all materials.
Applications
  • Chamfer Milling
  • Face Milling
Technical Data
  • Adapter Style: Straight-Cylindrical
  • Through Coolant: Yes
  • Number of Flutes: 3
  • Arbor Diameter (Inch): 0.7874"
  • Arbor Diameter (Metric): 20.000mm
  • Effective Cutting Diameter (Inch): 0.984"
  • Effective Cutting Diameter (Metric): 25.000mm
  • Maximum Cutting Diameter (Inch): 1.306"
  • Maximum Cutting Diameter (Metric): 33.180mm"
  • Maximum Cutting Depth (Inch): 0.127"
  • Maximum Cutting Depth (Metric): 3.230mm
  • Overall Length (Inch): 4.724"
  • Overall Length: 120.000mm
  • Max RPM: 20,000

Country of Origin is subject to change.

Safety data sheets upon request.
